10
CA-6220/8220
STEREO POWERED MIXER
Rear Panel Controls
Rear Panel Controls
1. POWER SWITCH
These standard 1/4” phone jacks and speaker connectors are the main speaker-level outputs from the
CA-6220/8220’s power amplifier. The CA-6220/8220 provides two pairs of stereo speaker output
jack, labeled L and R. The L and R jacks for each output channel are wired in parallel. If you connect a
speaker system may be as low as 4Ω.
~AC INPUT
PLEASE CONFIRM THE SPEAKER IMPEDANCE
NOT TO LESSEN 4 OHMS PER EACH CHANNEL.
(REFER OPERATING INSTRUCTIONS)
1- 1+
2+ 2-
SPEAKER
CONNECTOR
SCHEMATIC
DIAGRAM
AMP OUTPUT
MONO
NOT CONNECTED
LR
AMP OUT
PUSH TO
RESET
S
1
