Specifications
Specifications ..........................................................
0dB=0.775Vrms
- ELECTRICAL
- GENERAL
22
CA-6220/8220
STEREO POWERED MIXER
Maximum Output Power
(0.5% THD at 1kHz)
T.H.D
(20Hz~20kHz)
Frequency Response
Hum and Noise
(Average, Rs=150Ω)
(w/BPF 20Hz~20kHz)
Maximum Voltage Gain
Crosstalk (at 1kHz)
Input Channel Gain Control
Input Channel Equalization
Graphic Equalizer
Level Meters
Channel Peak Indicators
Phantom Power
Digital Effect
200W +200W/4Ω, 150W +150W/8Ω
Channel Input to LINE OUT: Less than 0.1%, 20Hz~20kHz, +4dB output
AMP IN to SPEAKER OUT:
Less than 0.1%, 20Hz~20kHz, 175W Output into 4Ω
+1, -3dB, 20Hz~20kHz, 1W into 4Ω
-128dB Equivalent Input Noise
-96dB Residual Output Noise (LINE Out)
-90dB Residual Output Noise (Effect Send, Monitor Out)
-73dB Residual Output Noise (Speaker Out)
-90dB (LINE OUT)
Master fader at maximum level
-77dB (EFFECT SEND)
Master fader at maximum level and all channel
EFFECT controls at minimum level.
-77dB (MONITOR OUT)
Master VR at maximum level and all channel
MONITOR controls at minimum level.
64dB MIC IN to LINE OUT, MON OUT
44dB LINE IN to LINE OUT, MON OUT
70dB MIC IN to SEND 1, 2
50dB LINE IN to SEND 1, 2
0dB RETURN 1, 2 to LINE OUT, MON OUT
12dB TAPE IN to LINE OUT, MON OUT
70dB Adjacent Input Channels
70dB Input to Output
44dB Variable from -60dB to -16dB (MIC)
44dB Variable from -40dB to +4dB (LINE)
±15dB Maximum boost or cut in each band
HIGH: 12kHz shelving
MID: 2.5kHz peaking
LOW: 80Hz shelving
* Turnover/Roll off frequency of Shelving: 3dB below
maximum variable level
±12dB Maximum boost or cut in each of nine bands
: 63, 125, 250, 500, 1k, 2k, 4k, 8k, 16kHz
10 Dot LED x 2
Red LED on each channel turns ON when LINE OUT signal reaches the level
3dB below clipping.
+48V is supplied to electrically balanced inputs to power condenser
microphones via 6.8kΩ current limiting/isolation resistors.
16 program selection
Power Source
Power Consumption
Weight
Dimensions
AC 110V – 240V, 50/60Hz
AC 120V: 310W, AC 230V–240V: 890W
20kg
440(W)
x
222(H)
x
258(D) mm
