Inter-m CA-8220 - Page 25

23
CA-6220/8220
STEREO POWERED MIXER
- INPUT
- OUTPUT
*0dB=0.775Vrms
0dBV=1Vrms
* Specifications and design subject to change without notice for improvements.
Input Input Nominal Input Connector Type
Connector Impedance Impedance Nominal Level
CH Mic 2kΩ 50-600Ω - 60dB XLR 3-31 Type
Balanced
CH Line 10kΩ 600Ω -40dB Phone Jack (TRS)
T=Hot
R=Cold
S=GND
EFX Return 1,2 10kΩ 600Ω +4dB Unbalanced
Phone Jack
Tape In 10kΩ 600Ω -10dBV RCA Pin Jack
AMP In 10kΩ 600Ω +4dB Phone Jack
T=Out
R=In
S=GND
Output Output Nominal Input Connector Type
Connector Impedance Impedance Nominal Level
AMP Out 4Ω or 8Ω 200W/4Ω Phone Jack
150W/8Ω Speaker Connect Jack
EFX Send 75Ω 600Ω +4dB Phone Jack
Monitor Out 75Ω 600Ω +4dB Phone Jack
REC OUT 600Ω 10kΩ -10dBV RCA Pin Jack
Line Out 600Ω 10kΩ +4dB Phone Jack
Phones Out 100Ω 40Ω 100mW Stereo Phone Jack
