11
H-3200/4200
PROFESSIONAL POWER AMPLIFIER
Applications
Applications
-2
- Bridge Mono Installation
- Binding post outputs
- Speakon™Outputs
BRIDGED
MONO
BRIDGED OUTPUT
(1+ 2+)
CH2 SPEAKON: NOT CONNECTED
NOT CONNECTED
NOT CONNECTED
