PROFESSIONAL AUDIO MIXER
5
MX-1646D
3. AUX 1~4 SEND
This volume adjusts the signal level sent to the aux bus. Aux send is post fader. It can be used to connect
additional equipment such as graphic EQ, compressor, etc.
■ Adjustment Range: -∞ ~ +6dB
4. FX SEND
It adjusts the signal level sent to the onboard effector processor.
■ Adjustment Range: -∞ ~ +6dB
5. PAN
This is a volume for dividing the input signal of each channel into MIX L / R output and group output
channel for use in stereo.
6. SOLO SWITCH
This switch mixes the signal to the SOLO bus so that you can individually check the signal on each channel
through the headphone, monitor output, and level meter. When the SOLO switch is pressed, the
corresponding PEAK/SOLO LED blinks in green.
7. PEAK/SOLO LED
The LED lights red in PEAK status and blinks green in SOLO status. When PEAK and SOLO are turned on at
the same time, the LED lights up in orange.
8. BUS ASSIGN SWITCH
MIX switch: Select this switch to send the corresponding input channel signal to the MIX channel.
G1 ~ G4 switch: Select this switch to send the corresponding input channel signal to the Group 1/2/3/4
channel respectedly.
9. INPUT CHANNEL VOLUME
It is a volume to adjust the level of the input channel. Keep the volume down when not in use.
■ Adjustment Range: -∞ ~ +10dB
