Inter-m PAM-324 - Specifications

PUBLIC ADDRESS AMPLIFIER
17
PAM-312/324/336/348
Specifications
Specifications
PAM-312 PAM-324 PAM-336 PAM-348
Rated Output Power
(1kHz, THD 1%)
70V/100V 120W 240W 360W 480W
Frequency Response
(1W, ±3dB, 20kHz LPF)
LINE 80Hz~15kHz
MIC 100Hz~15kHz
THD (Rated Power, 1kHz) Less than 1%
S/N, A-WTD
LINE Better than 70dB
MIC Better than 55dB
Input Sensitivity / Impedance
Input 1~3 /
Input Impedance
MIC -60dBV/2k (Balanced)
LINE -20dBV/2k (Balanced)
Input 4~5 / Input Impedance LINE -20dBV/30k (Balanced)
Input 6 / Input Impedance LINE -20dBV/20k (Un-Balanced)
TEL IN / Input Impedance -20dBV~0dBV/40k (Balanced)
EXT IN / Input Impedance 0dBV/40k (Balanced)
MIX OUT 0dBV (Balanced)
Speaker Output Level/Impedance
100V/84 100V/42 100V/27.7 100V/20.8
70V/41 70V/21 70V/13.6 70V/10.2
TONE CONTROL
BASS(100Hz)
±10dB
TREBLE(10KHz)
Operating Temperature
-10℃ ~ +40℃
Power Source AC 120V, 60Hz, AC 220-240V, 50/60Hz
Power Consumption (1/8W output) 50W 85W 95W 135W
Weight (Set) 7.26kg 6.88kg 6.93kg 7.16kg
Dimensions (Set) 420(W) x 132(H) x 358(D)mm
* Design and specification are subject to be changed for the improvement of product quality without pre notice.
