INTERFACE MODEL 9840 VER 6.0.2
Digital Display
Display Characters 2 lines by 20 characters
Display Update > 4/Sec
Scaling Automatic or manual
Maximum Display Count
± 999,999
Decimal Points. Selection 0 to 5 software selectable.
Display Type Vacuum fluorescent
Resolution 24 bit
Software Filters 8, software selectable
Electrical Characteristics
Power Requirements 110 VAC, 60 Hz, Optional 220VAC, 50 Hz
Power Consumption 12 W (unloaded)
Transducer Excitation Current Shutdown mode when shorted to ground
Absolute Max Transducer Input 30 VDC without damage
Physical Characteristics
Package Size 7.29” X 2.52 “ X 9.0” (W X H X D)
Case Material Aluminum
Mounting Hardware Available
Environmental
Operating Temp 0 C to 50 C
Storage Temp -10 C to 60 C
Relative Humidity 95 % without condensation
The Model 9840 is
compliant.
MODEL 9840 PG 54 PUB. 2856-16
