► These examples are typical for
both twin and concentric flue
bracket positioning.
max. 250 mm
max. 1000 mm
max. 1000 mm
max. 250 mm
max. 250 mm
max. 250 mm
max. 500 mm
fall back to boiler
Second element aer first elbow
Second element
aer first elbow
D E
F
