P/N INS518 • REV B • ISS 12MAR19 5 / 25
Input power
9 VDC to 15 VDC (15 VDC nominal @
10.6 mA)
Power rating 0.16 W
Peak to peak ripple
2 V (at 12 VDC)
Detector start-up time
60 seconds
Normal current
consumption (mA)
max. 8.7
Current consumption in
Alarm (mA)
max. 7.5
Max current
consumption (mA)
max. 10.6
Mounting height
6540 & 6550 Min. 1.5 m (4.1 ft), Max. 3.1 m
(10 ft.)
6540PI Min. 1.5 m (4.1 ft), Max. 2.3 m
(7.5 ft.)
Target speed range
30 cm/s to 3 m/s (1 ft/s to 10 ft/s)
Alarm relay
< 24 V 50 mA (NC) max. 34 Ω resistive
load
Tamper relay
< 24 V 50 mA (NC)
Alarm time
> 2 seconds
Operating temperature
-10˚C to +55˚C (14˚F to 130˚F)
Dimensions (H x W x D)
123 mm x 66 mm x 42 mm
Relative humidity
Max. 95%
Weight
94 g
Power supply
Rated 94HB
Regulatory information
Manufacturer
PLACED ON THE MARKET BY:
UTC Fire & Security Americas Corporation, Inc.
3211 Progress Drive, Lincolnton, NC, 28092,
USA
AUTHORIZED EU REPRESENTATIVE:
UTC Fire & Security B.V.
Kelvinstraat 7, 6003 DH Weert, Netherlands
Product warnings
and disclaimers
THESE PRODUCTS ARE INTENDED FOR
SALE TO AND INSTALLATION BY QUALIFIED
PROFESSIONALS. UTC FIRE & SECURITY
CANNOT PROVIDE ANY ASSURANCE THAT
ANY PERSON OR ENTITY BUYING ITS
PRODUCTS, INCLUDING ANY “AUTHORIZED
DEALER” OR “AUTHORIZED RESELLER”, IS
PROPERLY TRAINED OR EXPERIENCED TO
CORRECTLY INSTALL FIRE AND SECURITY
RELATED PRODUCTS.
For more information on warranty disclaimers and
product safety information, please check
https://firesecurityproducts.com/policy/product-
warning/ or scan the QR code.
Certification
European Union
directives
UTC Fire & Security hereby declares that this
device is in compliance with the applicable
requirements and provisions of the Directive
2014/30/EU and/or 2014/35/EU. For more
information see www.utcfireandsecurity.com or
www.interlogix.com.
2012/19/EU (WEEE directive): Products marked
with this symbol cannot be disposed of as
unsorted municipal waste in the European Union.
For proper recycling, return this product to your
local supplier upon the purchase of equivalent
new equipment, or dispose of it at designated
collection points. For more information see:
www.recyclethis.info
FCC Statement
Complies with FCC Part 15 Class B.
Maintenance
Test yearly by the installer
Warranty
5 year replacement warranty
Security grade
EN Grade 2 (Llarmklass 3)
Environmental
class
Class II
Standards
EN50131-2-2
The 6540, 6540PI and 6550 have been tested
and certified to EN50131-2-2 for Security Grade
2, environmental class II, by the Dutch testing
and certification body Telefication B.V.
Contact information
For contact information see our Web site:
www.utcfireandsecurity.com
DA: Installationsvejledning
Produktbeskrivelse
6540, 6550 og 6540PI er designet til at detektere en
indbrudstyvs bevægelser og aktivere en alarm på en central.
Produktet er beregnet til at blive sluttet til en angivet
indbrudssystem-kompatibel central eller en
strømforsyningsenhed med en forsyningsspænding mellem 9
og 15 V DC og med mindst 4 timers standby-strøm.
Installationsvejledning
Den anvendte teknologi i disse detektorer er modstandsdygtig
over for falske alarmer. Undgå imidlertid mulige årsager til
ustabilitet som f.eks. (se fig. 1):
• Direkte sollys på detektoren.
• Varmekilder inden for detektorens synsfelt.
• Kraftig træk på detektoren.
• Store dyr inden for detektorens synsfelt. (gælder ikke
versionen, der ikke registrerer kæledyr)
• Blokering af detektorens synsfelt med store genstande
som f.eks. møbler.
Ikke egnet til udendørs brug.
Sådan installeres detektoren
1. Løsn skruen på detektorens sokkel. Skruen bliver holdt
tilbage i produktet (se figur 2, trin 1).
2. Løft detektorens låg ud af soklen og af knopperne foroven
(se figur 2, trin 2).
