124 Advisor Advanced ATSx000A(-IP) Installation and Programming Manual
6.2.n.8 Log limit
If the Log limit option is set to Enable, only 3 pairs of activating (opening) and
restoring (or closing) events coming from a single output are recorded in the log
during one set/unset cycle.
Door control example
To program a door control function described in example on page 117, set the
following values:
• Select filter “Door open” for output 10.
Output 10 can then be used to unlock a door.
• Select Pulsed mode.
• Set Delay time to 00:00’00.
• Set Active time to 00:00’05 s.
See “6.1 Condition filters” on page 117 for more information.
6.2.n.9 Delete output
Use the Delete output screen to remove an output from the system. To remove
the output, select OK and press Enter again. The output is deleted.
