Interlogix Advisor Advanced ATS1000A-MM User Manual

Advisor Advanced ATSx000A(-IP) Installation and Programming Manual 17
Zone state
EOL
Connection
details [1]
Measure [2]
Short
Masking
Normal
Alarm
Fault
Open
4K7
(Item 4)
R (kΩ)
<1.00
1.00–
3.42
3.42–
6.67
6.67–
16.84
—
>16.84
RA=4.7 kΩ, RT=2.35 kΩ,
RF=2.35 kΩ
U (V)
<2.41
2.41–
5.79
5.79–
8.07
8.07–
10.74
—
>10.74
4K7
(Item 7)
R (kΩ)
<1.00
16.84–
55.00
1.00–
6.67
6.67–
11.75
11.75–
16.84
>55.00
RA=4.7 kΩ, RT=4.7 kΩ,
RF=10 kΩ
U (V)
<2.41
10.74–
12.70
2.41–
8.07
8.07–
9.82
9.82–
10.74
>12.70
2K2
(Item 4)
R (kΩ)
<0.73
0.73–
1.47
1.47–
2.93
2.93–
5.87
—
>5.87
RA=2.2 kΩ, RT=1.1 kΩ,
RF=1.1 kΩ
U (V)
<1.90
1.90–
3.30
3.30–
5.30
5.30–
7.70
—
>7.70
6K8
(Item 4)
R (kΩ)
<2.27
2.27–
4.53
4.53–
9.07
9.07–
18.13
—
>18.13
RA=6.8 kΩ, RT=3.4 kΩ,
RF=3.4 kΩ
U (V)
<4.50
4.50–
6.80
6.80–
9.10
9.10–
11.00
—
>11.00
5K6
(Item 4)
R (kΩ)
<1.87
1.87–
3.73
3.73–
7.47
7.47–
14.93
—
>14.93
RA=5.6 kΩ, RT=2.8 kΩ,
RF=2.8 kΩ
U (V)
<3.90
3.90–
6.10
6.10–
8.50
8.50–
10.50
—
>10.50
3K74
(Item 4)
R (kΩ)
<1.25
1.25–
2.45
2.45–
4.99
4.99–
9.98
—
>9.98
RA=3.74 kΩ, RT=1.87 kΩ,
RF=1.87 kΩ
U (V)
<2.90
2.90–
4.80
4.80–
7.10
7.10–
9.40
—
>9.40
3K3
(Item 4)
R (kΩ)
<1.10
1.10–
2.20
2.20–
4.40
4.40–
8.80
—
>8.80
RA=3.3 kΩ, RT=1.65 kΩ,
RF=1.65 kΩ
U (V)
<2.60
2.60–
4.40
4.40–
6.70
6.70–
9.00
—
>9.00
2K
(Item 4)
R (kΩ)
<0.67
0.67–
1.33
1.33–
2.67
2.67–
5.33
—
>5.33
RA=2 kΩ, RT=1 kΩ,
RF=1 kΩ
U (V)
<1.70
1.70–
3.00
3.00–
5.00
5.00–
7.30
—
>7.30
1K5
(Item 4)
R (kΩ)
<0.50
0.50–
1.00
1.00–
2.00
2.00–
4.00
—
>4.00
RA=1.5 kΩ, RT=0.75 kΩ,
RF=0.75 kΩ
U (V)
<1.30
1.30–
2.40
2.40–
4.10
4.10–
6.30
—
>6.30
2K2+4K7
(Item 3)
R (kΩ)
<3.60
—
3.60–
5.60
5.60–
8.20
—
>8.20
RA=2.2 kΩ, RT=4.7 kΩ
U (V)
<6.00
—
6.00–
7.50
7.50–
8.80
>8.80
