24 Advisor Advanced ATSx000A(-IP) Installation and Programming Manual
Device
Zones
Outputs
Device
Zones
Outputs
Expander 5
145–176
145–176
Keypad 5
—
1033–1040
Expander 6
177–208
177–208
Keypad 6
—
1041–1048
Expander 7
209–240
209–240
Keypad 7
—
1049–1056
Expander 8
241–272
241–272
Keypad 8
—
1057–1064
Expander 9
273–304
273–304
Keypad 9
—
1065–1072
Expander 10
305–336
305–336
Keypad 10
—
1073–1080
Expander 11
337–368
337–368
Keypad 11
—
1081–1088
Expander 12
369–400
369–400
Keypad 12
—
1089–1096
Expander 13
401–432
401–432
Keypad 13
—
1097–1104
Expander 14
433–464
433–464
Keypad 14
—
1105–1112
Expander 15
465–480 [2]
465–496
Keypad 15
—
1113–1120
Keypad 16
—
1121–1128
[1] Output 17 to 24 states are duplicated on ATS1810 relays and Expander 1 outputs.
[2] Inputs 17 to 32 of Expander 15 cannot be used.
