LED Keypad
ASSIGNING USER CODE AUTHORITY LEVELS
Assign authority levels to users by following the steps below. Assign user codes before
assigning authority levels.
1.
Press [
7
]-[
6
]-[“
Master Arm/Disarm Code
”].
Someone changing the authority of another person can only add or remove
partition authorization for partitions to which they have access.
2.
The
ready light
will flash.
3.
Enter the “user number” to be assigned authority. (Depending on the control
panel in your system, this will be either a 2-digit or 3-digit number. Always enter
leading zeros such as [
0
]-[
3
] for user 3, or [
0
]-[
5
]-[
2
] for user 52).
The
ready light
is constant and the
instant light
will flash.
Illuminated lights indicate the authority levels assigned to this code. An
explanation of the lights is listed in the following table. You may toggle (turn on/off)
the authority level by pressing the number for that authority level.
LIGHT AUTHORITY LEVELS IF LIGHT 8 IS OFF
1 Reserved (Note: Do not change if on.)
2 Arm Only
3 Arm Only After Closing Time
4 Master Arm/Disarm (can program other codes)
5 Arm/Disarm
6 Bypass Zones
7 Open / Close Reporting
8 If this light is on, this code is programmed as a function
code. Do not change! Press [#]-[#] to exit.
4.
5.
Press [
7
]. The
ready light
will flash. This moves you to the partition enable. (The
user has access in partitions that are illuminated.)
The illuminated numbers indicate each partition where the user has access. To
change any of the partitions where the user has access, press numbers
corresponding to areas where you want to give the user access or deny access.
(Example
: If zone light #2 is lit, then the user is assigned access to partition #2.
By pressing [
2
], the light will go off, denying access to partition #2.
Light Partition Light Partition
1 Partition 1 5 Partition 5
2 Partition 2 6 Partition 6
3 Partition 3 7 Partition 7
6.
4 Partition 4 8 Partition 8
