Interlogix Caddx User Manual

LED Keypad

UNDERSTANDING THE LIGHTS
ABORT LIGHT
The
abort light
will flash during an abort delay time. If a code is entered while this light
is flashing, all abortable reports will stop the communication process.
Note: The abort
feature must be enabled
. Entering a code during or after an alarm report to the
central station will cause the
abort light
to come on. It will stay on until the central
station has received the cancel report.
Note: The cancel feature must be enabled.
AWAY - STAY - NIGHT KEYS
The
away, stay, and night keys
are “on” when the system is armed to one of these
corresponding modes. The
armed, stay, and night keys
are “off” when it is disarmed.
The
armed, stay, and night keys
will flash when there has been an alarm during the
previous arm cycle.
BYPASS KEY
The
bypass key
is illuminated when any zone in this keypad’s partition is bypassed.
The zone(s) that is bypassed will also be illuminated. If the
bypass key
is “off”, no
zones are bypassed.
CHIME LIGHT
The c
hime light
is “on” when the chime feature is “on”; “off” otherwise.
FIRE LIGHT
A steady
fire light
means a fire zone has been faulted. A rapidly flashing
fire light
means that a fire zone is in a trouble condition.
POWER LIGHT
The
power light
is on if the primary power is on. The
power light
will flash if the system
has a low battery condition.
READY LIGHT
The
ready light
is “on” when the system is ready to arm and “flashes” if ready to force
arm. The
ready light
is off when the system is not ready to arm because of a zone(s)
being faulted.
SERVICE LIGHT
The service light is “on” when the system requires service. Press [
7
]-[2] to determine
the service condition then refer to page 13 for details.
ZONE LIGHT
The
zone lights
are “off” when everything is normal. A
zone light
will be “on” if the zone
has been bypassed. If a
zone light
is “flashing”, that zone is in alarm or has been
faulted. If a
zone light
is “flashing” rapidly, it means that the zone is in a trouble
condition. Trouble conditions are:
Tamper Hardware Low Battery Loss of Supervision
(A combination of Alarm/Fault and Tamper/Trouble will produce a rapid “flashing” light
for a short period of time, followed by a slow “flashing” light.)
