UVD-IP-XP4DNR(-P) Camera 3 - EN
• If the light source where the camera is installed experiences rapid,
wide-variations in lighting, the camera may not operate as
intended.
WARNING: To reduce the risk of fire or electronic shock, do not
expose the camera to rain or moisture and do not remove the cover or
back.
Package contents
The UVD-IP-XP4DNR(-P) camera is shipped with the following items:
• The camera assembly
• 1 channel passive video transceiver
• AC power wiring harness
• Mounting screws, wall anchors, and hex key
• 150 mm DC jack to terminal adapter
Use the video output BNC and power jack for normal system
operation.
Figure 1: Camera assembly
Camera body
RJ45 Ethernet/PoE input
24 VAC / 12 VDC input
Video output (BNC)
Plenum-compliant cabling
The cable connections must be enclosed in a suitable metallic, or other
fire-resistant, low-smoke producing enclosure. The cabling used within
