Intermec CK3 User Manual

Chapter 4 — Troubleshooting and Maintaining the CK3
78 CK3 Mobile Computer User’s Manual
To cold boot your CK3
1 Press and hold for about 2 seconds to suspend the CK3.
2 Remove the battery.
3 Use the stylus to press the reset button in the battery
compartment of the CK3.
4 Replace the battery.
Clean Booting the CK3
If the CK3 does not warm boot or cold boot, you may need to perform
a clean boot. When you clean boot the CK3, the CK3 only loads files
and applications that are absolutely required by the operating system.
Perform a clean boot to get the CK3 up and running so that you can
run diagnostic tests to troubleshoot the normal boot process.
Reset button
Do not use force or a sharp object when pressing the reset
button. You may damage the reset button.
The clean boot process erases the CK3 memory, including all
applications and data files in the object store. To preserve
applications through a clean boot, store them in the Flash File
Store. For more information, see “Installing Applications on the
CK3” on page 55.

Intermec CK3 Specifications

General

RAM capacity	128 MB
Certification	GS, EN55022 Class B, ICES-003 Class B, EN 300.328, FCC Part 15.247, RSS-210, EMC, FCC Part 15, R&TTE, RoHS, WEEE, cULus
Product color	Gray
Internal memory	512 MB
Built-in display	Yes
Housing material	-
Display resolution	240 x 320 pixels
Display technology	TFT
Processor frequency	520 MHz
Bluetooth version	2.0+EDR
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Operating system installed	Windows Mobile 6
Type	Handheld bar code reader
Scanner type	1D/2D
Power source type	Battery
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	36 mm
Width	84 mm
Height	217 mm
Weight	453 g
