Intermec EasyCoder PX4i Spare Parts

Chapter 1 — Introduction
4 EasyCoder PX4i and PX6i Printers Spare Parts Catalog
EasyCoder PX6i, General View
Callout Description Remarks
1 Transfer ribbon mechanism See pages 11-13
2 Various types of interface boards (options) See pages 26-30
3 Fan fold guides kit (option) See page 35
4 Media supply with accessories See pages 15, 16-18
5 Liner/batch takeup unit (option) See page 22
6 Label slack absorber See page 20
7 Chassis See pages 7-8
8 Cutter kit (option) See page 33
9 Print unit See page 10
10 Label taken sensor kit (option) See page 22
11 Keyboard and console board See page 6
Closed
Open
11
10
9
8
7
6
5
4
3
2
1

Intermec EasyCoder PX4i Specifications

General

Print technology	Direct thermal
Maximum resolution	300 x 300 DPI
Display	LCD
Product color	Silver
Keyboard layout	Numeric
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Media thickness	2.4/10 mm
Maximum label width	120 mm
Maximum label length	2.7 m
Maximum roll diameter	213 mm
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Power requirements	90 - 265 VAC, 45 - 65Hz
Power consumption (standby)	20 W
Power consumption (printing)	125 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	482 mm
Width	238 mm
Height	275 mm
Weight	12850 g
