Intermec EasyCoder PX4i Spare Parts

Chapter 2 — Spare Parts
EasyCoder PX4i and PX6i Printers Spare Parts Catalog 21
Liner/Batch Takeup Unit, EasyCoder PX4i
Callout Part Number RoHS Number Description Remarks
1 1-040960-90 1-040960-900 Stepper motor assembly Includes pulley
2 1-995101-43 1-995101-43 Timing belt
3 1-040187-00 1-040187-01 Takeup unit assembly Complete unit
4 1-040317-01 1-040317-01 Brace
5 1-040335-01 1-040335-01 Bobbin plate
6 1-040253-01 1-040253-01 Batch takeup plate
7 1-040239-90 1-040239-90 Belt stretcher kit
8 1-995101-53 1-995101-53 Timing belt
1
2
8
7
6
5
4
3

Intermec EasyCoder PX4i Specifications

General

Print technology	Direct thermal
Maximum resolution	300 x 300 DPI
Display	LCD
Product color	Silver
Keyboard layout	Numeric
Standard interfaces	RS-232, USB 2.0
Internal memory	16 MB
Media thickness	2.4/10 mm
Maximum label width	120 mm
Maximum label length	2.7 m
Maximum roll diameter	213 mm
Supported network protocols	TCP/IP, LPR/LPD, FTP, BOOTP, DHCP, HTTP, SNMPv3, SMTP, SNMP-MIB II
Power requirements	90 - 265 VAC, 45 - 65Hz
Power consumption (standby)	20 W
Power consumption (printing)	125 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	40 - 104 °F
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	482 mm
Width	238 mm
Height	275 mm
Weight	12850 g
