UM062TW / UM562TW UDM10010-01
11
SPECIFICATIONS
Operating Conditions
Use in a dry, relatively clean environment at 40º to 105º F (5º to 40º C) with clean dry
cartons.
Tape
1) General
Use Intertape brand Pressure Sensitive Carton Sealing Tape.
2) Tape Width
1.5 to 2 inch wide tape (36 to 48 mm) maximum.
3) Tape Roll Diameter
Maximum of 16 inches (405 mm) on a 3-inch (76.2 mm) diameter core.
(Accommodates all Intertape brand film tape machine roll lengths).
4) Tape Application Leg Length – Standard
2.5 inches (+0.25", -0") (63.5 mm, +6.3 mm, - 0 mm).
5) Tape Application Leg Length – Optional
2 inches (+0.25", -0.5") (50.8 mm, +6.3 mm, -12 mm). Refer to HSD
2000
Tape Head manual for adjustment of tape application leg length.
Box Board
Style: regular slotted containers (RSC)
125 to 275 psi bursting test, single or double wall B or C flute.
Carton Weight Capacity: Up to 85 lbs.
