UM094TW / UM594TW UDM094-04
20
5. Carton Specifications
Type
Regular Slotted Containers (RSC)
Other Style Cases May Be Processed. Consult Factory For Details.
Material
125 To 275 PSI Bursting Test, Single Or Double Wall B Or C Flutes.
Weight
0 to 85 lbs. (0 to 38.6 kg)
Size
The case sealer can accommodate most cartons within the size ranges listed below.
Case Processing Stability
For optimal performance, the cases should be stable when processing through the machine.
Unstable cases may tilt backwards upon contact with the upper tape head causing the machine
to jam.
If the box length (in direction of seal) to box height ratio is .75 or less, then several boxes should
be test run to assure proper machine performance. The formula is as follows;
CARTON LENGTH IN DIRECTION OF SEAL > .75
CARTON HEIGHT
Machines Equipped With 2” Tape Heads
Carton Size Length Width Height
Minimum
6” (150mm)
8” (203mm) opt.
3.5” (89mm)
8” (203mm) opt.
3.5” (89mm)
2” (50.8mm) opt.
Maximum
Infinite 20” (508mm) 24” (610mm)
Machines Equipped With 3” Tape Heads
Carton Size Length Width Height
Minimum
6” (150mm)
8” (203mm) opt.
4.5” (114mm)
8” (203mm) opt.
3.5” (89mm)
2” (50.8mm) opt.
Maximum
Infinite 20” (508mm) 24” (610mm)
