UM094TW / UM594TW UDM094-04
22
SET-UP PROCEDURES
2. Caster Installation (If Purchased)
Caster Installation Requires Raising The Machine To Access The Bottom Of Each Leg.
Please Follow All Possible Safety Procedures Prior To And During This Process
A. With A Fork Lift, Raise The Machine To Allow Access To The Bottom Of Each
Leg
B. Screw In A Caster Into A Leg Until It Is Firmly Seated To The Bottom Of The
Leg.
C. Tighten Each Caster
D. Do Not Adjust The Conveyor Height By Adjusting The Caster. Proper
Conveyor Height Must Be Achieved By Adjusting The Leg Extension Of Each
Leg. (See Figure-7)
Figure-7
