S ET -U P P ROCEDURES
5. Installation of External In-Feed and Exit Conveyors
Figure-10
1. Customer supplied in-feed conveyor (if used) should provide straight and level entry into
the case sealer.
2. Customer supplied gravity exit conveyor (if used) should be straight and declined no
more than 20mm/meter away from the machine to convey the sealed cartons away from
the machine.
3. Customer supplied powered exit conveyor should be straight and level to convey the
sealed cartons away from the machine.
Exit Conveyor
In-Feed Conveyor
