UM094TW / UM594TW UDM094-04
32
SET-UP PROCEDURES
WARNING! THE KNIFE CONTAINED IN THE TAPE HEAD IS EXTREMELY SHARP. USE CAUTION
WHEN THREADING THE TAPE TO AVOID PERSONAL INJURY
.
11. Tape Threading Preparation
Figure-19
Threading the tape in the Tape Head does not require any special tools.
Pull approximately twelve (12) inches of tape from the roll and fold in half lengthwise, adhesive
side to adhesive side. This allows you to thread the tape without it adhering to the guide and
clutch rollers inside the Tape Head
12
