UM094TW / UM594TW UDM094-04
34
S ET -U P P ROCEDURES
13. Re-Installing Tape Heads
Figure-22
1. Insert Exit End of Tape Head into Rear Slots.
2. Rotate Front of Tape Head Down Into Front Slots
3. Push Front of Tape Head Down to Seat in Bottom of Slot.
