25
User Manual
4. 50-200 FISH FINDER
This chapter provides instructions to assist in planning the installation of the
50-200 FISH FINDER.
4.1 TECHNICAL SPECIFICATIONS
♦ Display Colors : 16 colors on color chart plotter or 16 gray
levels on gray levels chart plotter
♦ Display Vertical Resolution : up to 400 pixels (depending on chart
plotter screen resolution)
♦ Power Requirements : 10 - 35 Volt dc
♦ Over Voltage protection
♦ Reverse Polarity protection
♦ Power Consumption - operating:17W max
♦ Power Consumption - stand by : 1.7W max
♦ Operating Frequency : Dual 50 and 200kHz
♦ Output Power : 500/1000W (4000/8000Wpp)
♦ Depth Range*
1KW/200kHz : 2.5Ft (0.76m) to 1200Ft (366m)
Max Typical = 980Ft (299m)
1KW/50kHz : 5Ft (1.52m) to 4000Ft (1219m)
Max Typical = 2700Ft (823m)
500W/200kHz : 2.5Ft (0.76m) to 700Ft (213m)
Max Typical = 600 Ft (183m)
500W/50kHz : 5Ft (1.52m) to 1500Ft (457m)
Max Typical = 1350 Ft (411m)
NOTE* This is not a guaranteed specification. The actual maximum depth capability
of the system depends on the type of transducer fitted, the reflectivity of the
bottom, water condition, etc.
♦ Status LED
♦ External Buzzer : 12VDC, 400mA
♦ Speed Sensor : if available on transducer
♦ Temperature Sensor : one channel TEMP1 (if available on
transducer), optional second channel
TEMP2
♦ NMEA Output sentences : Depth: $SDDPT, $SDDBT
Speed: $VWVHW
Trip Log: $VWVLW
Water Temperature: $YXMTW
TEMP2 Temperature: $YXXDR
♦ Operating temperature range : 0C to +50C
♦ Storage temperature range : -20C to +70C
♦ Weight : 1 kg (2,20 LBS)
♦ Water Proof Specification : IP 54
♦ Case Size : 7.62" (193.30mm) x 6.87"
(174.30mm) x 2.19" (55.50mm)
