36
Display Type: 480 x 234 pixels, Sunlight Color Active Matrix LCD
Depth Ranges: Depth ranges, 0 - 25 to 0 - 600feet
Forward Ranges: Forward ranges, 0 - 50 to 0 - 1,200 feet
Transmit Frequency: 200 kHz
Transmite Power: Approx. 450 RMS or 3,600 peak-to-peak Watts
Transmit Beam Angle: Approx. 12 degrees
Pulselength and
Sounding Rates: Automatically optimized for selected range.
Power Requirements: 11 to 16 VDC, less than 1.2Amp.
Operating Temperature: 0 to 50 degrees C (32 to 122 degrees F)
NMEA 0183 Inputs: GLL, VTG, MTW
NMEA 0183 Output DBT, DPT
Dimensions: 9.5”W x 5.9”H x 3.25”D
Standard Equipment: Display with protective cover, Quick Disconnect Mounting Bracket with
Power/IO cable, in-line fuse, operation manual and depth transducer
with 30’ cable.
Specifications
Thru-Hull Transducer
Part # T1-I200-026
Transom Transducer
Part # T1-I200-025
