Interpump Hydralok HydraTouch H50 - TECHNICAL INFORMATION AND SPARE PARTS

Machines manufactured by Hydralok, Bristol, UK
Machine enquiries, sales, after sales service :
Interpump Hydraulics (UK) Ltd t/a IMM Hydraulics (UK) : Kidderminster
Tel : (0)121 550 1115 / sales@immhydraulics.co.uk
22
TECHNICAL INFORMATION
Maintenance And Service:
A monthly check on the oil level should be carried out, more frequently for machines in
regular or constant use.
The sliding surfaces of the head must be regularly lubricated with a molybdenum-
disulphide based grease. A thin coat of grease on the aforementioned surfaces (see
page 16) when prompted should be sufficient but for machines operating continuously or
in hot climates it may require more frequent applications.
At yearly intervals it is recommended to re-calibrate the swaging head.
EIL recommend the swaging head to be serviced every 12 to 18 months, depending on
frequency of use. A re-calibration and full service is available from the manufacturer or
authorized distributor.
Spare Parts:
(See Figure 1, Page 22)
H32HydraTouch
Item
Part Number
Description
9, 10,11,12,13,14
300-078
Seal kit
18,19,20,21
300-079
Spring kit
(optional)
123-070
Gas Struts
H50HydraTouch
Item
Part Number
Description
9, 10,11,12,13,14
300-072
Seal kit
18,19,20,21
300-064
Spring kit
(optional)
123-069
Gas Struts
H50-46HydraTouch
Item
Part Number
Description
9, 10,11,12,13,14
300-126
Seal kit
18,19
300-125
Spring kit
Replaces Spring Kit
123-080
Gas Struts
H50-6HydraTouch
Item
Part Number
Description
9, 10,11,12,13,14
300-108
Seal kit
18,19, 20, 21
300-128
Spring kit
(optional)
123-085
Gas Struts
