Interroll 138i - Oil Quantities for the I-Series in Liters (Standard Installation)

Interroll Drum motor series i, S, S/A, D
Maintenance and cleaning
Version 4.1 (06/2015) en-US
Translation of original instruction manual
93
SL
mm
80i 113i 138i 165i 217i* 217i
SL
min
=
250 mm
SL
min
=
300 mm
SL
min
=
300 mm
SL
min
=
350 mm
SL
min
=
400 mm
SL
min
=
450 mm
SL
min
=
400 mm
SL
min
=
500 mm
200 0.12
250 0.14 0.40
300 0.17 0.50 0.40 0.70
350 0.21 0.60 0.40 0.80 0.70
400 0.25 0.60 0.50 1.00 0.80 1.20 3.10
450 0.29 0.70 0.60 1.10 1.00 1.40 1.20 3.30 2.0
500 0.32 0.80 0.70 1.30 1.10 1.60 1.40 3.70 2.1
550 0.36 0.90 0.80 1.40 1.30 1.80 1.60 4.10 2.3
600 0.40 1.00 0.90 1.60 1.40 1.90 1.80 4.50 2.6
650 0.44 1.10 1.00 1.70 1.60 2.10 2.00 4.90 2.9
700 0.48 1.20 1.10 1.90 1.70 2.30 2.10 5.30 3.1
750 0.51 1.30 1.20 2.00 1.90 2.50 2.30 5.70 3.4
800 0.55 1.40 1.30 2.20 2.00 2.70 2.50 6.10 3.6
850 0.59 1.50 1.40 2.30 2.20 2.90 2.70 6.50 3.9
900 0.63 1.60 1.50 2.50 2.30 3.10 2.90 6.90 4.1
950 0.67 1.70 1.60 2.60 2.40 3.30 3.10 7.30 4.4
1000 0.70 1.80 1.70 2.70 2.60 3.50 3.30 7.70 4.7
1050 1.90 1.80 2.90 2.70 3.70 3.50 8.10 4.9
1100 2.00 1.90 3.00 2.90 3.80 3.70 8.50 5.2
1150 2.10 2.00 3.20 3.00 4.00 3.90 8.90 5.4
1200 2.20 2.10 3.30 3.20 4.20 4.00 9.30 5.7
1250 2.30 2.20 3.50 3.30 4.40 4.20 9.70 6.0
1300 2.40 2.30 3.60 3.50 4.60 4.40 10.10 6.2
1350 2.50 2.40 3.80 3.60 4.80 4.60 10.50 6.5
1400 2.60 2.50 3.90 3.80 5.00 4.80 10.90 6.7
1450 2.70 2.60 4.10 3.90 5.20 5.00 11.30 7.0
1500 2.80 2.70 4.20 4.10 5.40 5.20 11.70 7.2
1550 2.90 2.80 4.40 4.20 5.60 5.40 12.10 7.5
1600 3.00 2.90 4.50 4.40 5.70 5.60 12.50 7.8
Oil quantities for the
i-series in liters
(standard installation)
