BladeLF1
Enter offset mode, Select BladeLF1, press the ENTER button to confirm, the present position will
blink on the display, use the UP/DOWN button to offset the value from 000 to 255, press the ENTER
button to store. Press the MENU button to exit.
BladeLF2
Enter offset mode, Select BladeLF2, press the ENTER button to confirm, the present position will
blink on the display, use the UP/DOWN button to offset the value from 000 to 255, press the ENTER
button to store. Press the MENU button to exit.
BladeRG1
Enter offset mode, Select BladeRG1, press the ENTER button to confirm, the present position will
blink on the display, use the UP/DOWN button to offset the value from 000 to 255, press the ENTER
button to store. Press the MENU button to exit.
BladeRG2
Enter offset mode, Select BladeRG2, press the ENTER button to confirm, the present position will
blink on the display, use the UP/DOWN button to offset the value from 000 to 255, press the ENTER
button to store. Press the MENU button to exit.
4.1.3 Animation Module Address Setting
If you use a universal DMX controller to control the units, you have to set DMX address from 1 to
512 so that the units can receive DMX signal.
Press the MENU button to enter menu mode, select DMX Setting, press the ENTER button to
confirm, use the UP/DOWN button to select Address, press the ENTER button to confirm, the
present address will blinking the display, use the UP/DOWN button to adjust the address from 001
to 512, press the ENTER button to store. Press the MENU button back to the last menu or let the
unit idle 30 seconds to exit menu mode.
Please refer to the following diagram to address your DMX512 channel for the first 4 units.
Channel mode
Unit 1
Address
Unit 2
Address
Unit 3
Address
Unit 4
Address
34 channels 1 35 69 103
29 channels 1 30 59 88
