Intertek Acme Solat Impulse - Gobo Module DMX512 Configuration

Please refer to the following diagram to address your DMX512 channel for the first 4 units.
Channel mode
Unit 1
Address
Unit 2
Address
Unit 3
Address
Unit 4
Address
34 channels 1 35 69 103
25 channels 1 26 51 76
29 channels 1 30 59 88
20 channels 1 21 41 61
4.2.4 Gobo Module DMX512 Configuration
Please refer to below configurations to control the fixtures
Attentions:
1. The unit will maintain the last condition until reset if you cut-off the DMX signal.
2. For the channel Function, keep the value for about 3 seconds, then the corresponding function
will take into effect.
34 Channels (Mode 1):
CHANNEL VALUE FUNCTION
1
000-255
PAN
0°

540°
2 000-255 Pan Fine
3
000-255
TILT
0°

270°
4 000-255 Tilt Fine
5
000-255
X/Y Time
Fast to Slow
6
000-255
Cyan
0%

100%
7
000-255
Magenta
0%100%
8
000-255
Yellow
0%

100%
9
000-255
CTO
0%100%
10
000-009
Color
Open
