4.1.4 Animation Module DMX512 Configuration
Please refer to below configurations to control the fixtures
Attentions:
1. The unit will maintain the last condition until reset if you cut-off the DMX signal.
2. For the channel Function, keep the value for about 3 seconds, then the corresponding function
will take into effect.
34 Channels (Mode 1):
CHANNEL VALUE FUNCTION
1
000-255
PAN
0°

540°
2 000-255 PAN FINE
3
000-255
TILT
0°

270°
4 000-255 TILT FINE
5
000-255
X/Y Time
Fast to Slow
6
000-255
Cyan
0%

100%
7
000-255
Magenta
0%100%
8
000-255
Yellow
0%

100%
9
000-255
CTO
0%100%
10
000-009
010-018
019-027
028-036
037-045
046-063
064-127
128-189
190-193
194-255
Color
Open
Color1
Color2
Color3
Color4
Color5
Color Index
Fast to Slow
Stop
Slow to Fast
11
000-009
010-018
019-027
028-036
Gobo
Open
Gobo1
Gobo2
Gobo3
