Construction:
Display: LCD display
Battery backup for user setup without mains connection
Data In/Out: 3-pin and 5-pin XLR, RJ-45
Power In/Out: Power Connector in/out
Protection Rating: IP20
Features:
Linear CMY color mixing
Variable CTO
1 x animation wheel with outstanding water and flame effect, the effect disk can rotate and
replaced
1 x 4-facet prism rotating in both directions
Motorized linear iris
4 x fast and smooth framing shutters, the position and the angel of each shutter blade can be
controlled individually; Each shutter blade can block out light completely, the framing module can
be rotated at ± 45 degrees
2 x fixed clamps for 50mm truss, 2 x pairs locking points of removable clamp for 70mm truss
Dimension/Weight:
465× 352×836mm, 46.3Kgs (Standard Version)
465× 352×820mm, 46.3Kgs (The Clamp and Quick-lock Fastener Version)
18.3"x13.9"x32.9"in, 102.1lbs (Standard Version)
18.3"x13.9"x32.3"in, 102.1lbs (The Clamp and Quick-lock Fastener Version)
