Intex 26363EH User Manual

119
PO
SAVE THESE INSTRUCTIONS
(119PO) ULTRA XTR™ RECTANGULAR / PRISM FRAME™ POOLS ENGLISH 7.5” X 10.3” PANTONE 295U 05/14/2020
English
Page 12
POOL SETUP
(
continued
)
2.4
32’ X 16’
CORNER
JOINT
CORNER
JOINT
CORNER
JOINT
CORNER
JOINT
(A)
(F)
(D)
(E)
(E)
(D)
(F)
(E)
(E)
(C)
LINER
(B)
(B)
(B)
(B)
(B)
(B)
(C)
(A)
(B)
(B)
(B)
(B)
(B)
(B)
3.
Be sure the liner is opened and spread out to its fullest
 extentontopofthegroundcloth.Startingwithoneside,
 slidethe“A”beamsfirstintothesleeveopeningslocatedin
 eachcorner.Continuewith“B”beamsnappingintothe“A”
 beam,andanother“C”beamsnappingintothe“B”beam
(see drawing 3)
.
 Keepthemetalbeamholesalignedwiththewhiteliner
 sleeveholes.
 Continueinsertingall“A-B-C&D-E-F”beamsintothesleeve
 openings.Startthe"D-E-F"combinationforpool'sshortsides
 byinsertingthe"D"beamfirstintotheopening. 
 Thecombinationsforbeamsaredifferentfordifferentsizesofpools,seethechartbelowfordetail.(Be
 sureall4sidesendupwiththemetalbeamholesalignedwiththewhitelinersleeveholes.)
4.
Slidetherestrainerstrap
(13)
onto the large U-shaped side
support
(11)
. Repeat for all restrainer straps and U-supports.
IMPORTANT: The liner is to remain flat on the ground
during the next step #5. This is why 5 - 6’ of clearance
space around the pool is necessary (see drawing 4).
4
13
9
10
11
3
(C)
(B)
(B)
(A)
SizeofPool
157-1/2”x78-3/4”(400cmx200cm)
118-1/8”x68-3/4”(300cmx175cm)
15’x9’(457cmx274cm)
16’x8’(488cmx244cm)
18’x9’(549cmx274cm)
24’x12’(732cmx366cm)
32’x16’(975cmx488cm)
No.of“U-shape”Leg
on longer side
4
3
4
4
4
6
8
No.of“U-shape”Leg
on shorter side
2
1
2
2
2
3
4
HorizontalBeam
Combinations on longer side
A-B-B-C
A-B-C
A-B-B-C
A-B-B-C
A-B-B-C
A-B-B-B-B-C
A-B-B-B-B-B-B-C
HorizontalBeam
Combinations on shorter side
D-F
D-E-F
D-F
D-F
D-F
D-E-F
D-E-E-F
