POOL SETUP
(
continued
)
5.
ThetopsoftheU-shapedsidesupportshaveadouble
button spring loaded clip
(10)
that is factory pre-installed.
 Insertthesidesupportsintothe“A-B-C&D-E-F”beam
 holesbysqueezingthebottombuttoninwardwithyour
fingers.
 Squeezingthisbottombuttonwillallowthesupporttoenter
the beam. Once the U-support is inside the beam release
 thefingerpressureallowingthesupportto“SNAP”into
place. Repeat this procedure for all U-shaped side supports
(see drawing 5)
.
6.
Withonepersonstandinginsidethepool,raiseonecorner;
insert the connecting rod
(12)
intotheoverlappingopenings,
to connect the liner straps to the restrainer straps. Repeat
the operation in the other corners and then
on the sides
(see drawings 6.1 & 6.2)
.
7.
Pull the bottoms of the side supports out away from the
liner to make the straps taut. Repeat for all locations
(see drawing 7)
.
8.
Ifthegroundisnotconcrete(asphalt,lawnorearth)you
 mustplaceapieceofpressure-treatedwood,size
 15”x15”x1.2”,undereachlegandset flush with the
ground. The U-shaped side supports must be placed in
the center of the pressure-treated wood and with the wood
grain perpendicular to the support leg
(see drawing 8
).
NOTE:
Make sure each support pad is recessed and set
flush with the ground and not just placed on the ground.
 Donotusesupportpadsorslabswithslippery,smooth
surfaces as the U-shaped side support will slide outward
 causingdamagetothepoolandvoidthewarranty.
5
13
11
10
6.1
6.2
LINER
LINER
12
7
12
8
Level
