PPAARRTTSS RREEFFEERREENNCCEE
PARTS REFERENCE (continued)
Before assembling your product, please take a few minutes to check the contents
and become familiar with all the parts.
NOTE: Drawings for illustration purpose only. May not reflect actual product. Not to
scale.
9
10
11 12 13 14 15
9
10
11 12 13 14 16
9
10
11
12
13
14
15
16
REF. NO.
DESCRIPTION
QTY.
SPARE PART NO.
2
2
2
2
1
1
PLUNGER VALVE (HOSE O-RING & STEP WASHER INCLUDED)
HOSE O-RING
STEP WASHER
STRAINER NUT
FLAT STRAINER RUBBER WASHER
THREADED STRAINER CONNECTOR
ADJUSTABLE POOL INLET NOZZLE
STRAINER GRID
10747
10262
10745
10256
10255
10744
11074
10253
