Intex Krystal Clear 634T User Manual

(110) MODEL 634 FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/06/2016
110A
SAVE THESE INSTRUCTIONS
English
Page 5
PARTS REFERENCE (continued)
Before assembling your product, please take a few minutes to check the contents
and become familiar with all the parts.
NOTE:
Drawings for illustration purpose only. Actual product may vary. Not to scale.
9*
10*
11*
12*
13*
14*
15*
16
17*
18*
19*
20*
REF. NO.
DESCRIPTION
QTY.
SPARE PART NO.
2
2
2
1
1
2
1
1
1
1
10747
10262
10745
10256
10255
11235
12369
10712
12198
12363
12371
12373
PLUNGER VALVE (HOSE O-RING & STEP WASHER INCLUDED)
HOSE O-RING
STEP WASHER
STRAINER NUT
FLAT STRAINER RUBBER WASHER
THREADED STRAINER CONNECTOR
ADJUSTABLE POOL INLET JET NOZZLE
HOSE O-RING
STRAINER GRID
AIR JET VALVE
INLET THREADED AIR CONNECTOR
AIR JET VALVE CAP (NOT SHOWN)
9
10
11 12 13 14
*
17
" * ":
Optional.
When ordering parts, be sure to quote the model number and part numbers.
9
10
11
12
13
15
*
19
18
