(110) MODEL 634 FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/06/2016
110A
SAVE THESE INSTRUCTIONS
English
Page 4
PARTS REFERENCE
Before assembling your product, please take a few minutes to check the contents
and become familiar with all the parts.
When ordering parts, be sure to quote the model number and part numbers.
NOTE:
Drawings for illustration purpose only. Actual product may vary. Not to scale.
REF. NO.
DESCRIPTION QTY. SPARE PART NO.
1 THREADED FILTER HOUSING COLLAR 1 10491
2
AIR RELEASE VALVE/SEDIMENT RELEASE VALVE
2 10460
3 VALVE O-RING 2 10264
4 FILTER HOUSING COVER 1 10490
5 FILTER HOUSING O-RING 1 10492
6 FILTER CARTRIDGE (29005) 1
7 AIR RELEASE VALVE B (WITH O-RING) 1 10725
8 PUMP HOSE WITH NUTS 2 11010
Type of lter medium Synthetic cartridge #29005
2
3
4
5
1
6
8
7
3
2
16
16
No tools are required for the assembly.
