Intex PureSpa SB-H20 Repair Guide

Page 28
Black blank
Blank Panel
A blank reading on a spa Control Panel indicates components such as RCD failure, PCB failure or a
connection issue between the Panel & Base.
1. Test the socket voltage, is the voltage is close to wall output?
2. Reconnect Signal Line, reference to Page 12 (Opening the Control Base) for signal connection.
3. Replace a control panel, and power on the system again.
4. If blank panel still persists, replace a new PCB or RCD, refer to the section replacing the PCB or
RCD for more details.
1. Replace PCB, or
2. Replace RCD, or
3. Replace Power Cord
Replace a control panel, run system
END
Plug in and Reset RCD
Reconnect Signal Line
Panel Blank?
Panel Blank?
No
Yes
No
Yes

Intex PureSpa SB-H20 Specifications

General

Control Panel	Digital
Air Jets	120
Brand	Intex
Type	Inflatable Hot Tub
Digital Control Panel	Yes
Seating Capacity	4 person
Water Capacity	210 gallons
Bubble Jets	120
Heating System	Yes
Cover	Included
Height	28 inches
Model	SB-H20
