Intex PureSpa SB-H20 Repair Guide

Page 3
28426 Internal Part
REF.
SP#
QTY
DESC
1
12840
1
SPA CONTROL PANEL FOR 28425/28426
2
12913
1
BUBBLE SPA CONTROL BASE BACK COVER-KHAKI
3
12770W
2
CONTROL BASE SIDE COVER
5
12846
1
PTC HEATER FOR 28442
6
12848
1
AIR BLOWER FOR 28442
8
12836
1
SPA CONTROL BASE FOR 28426/28428/28476
9
11998
1
SPA RCD
10
12914
1
AIR PIPE SET DOWNWARD FOR BUBBLE SPA-KHAKI
11
12915
1
WATER INLET TUBE FOR BUBBLE SPA-KHAKI
12
12916
6
SCREW FOR SPA BASE
13
12917
1
BUBBLE SPA BASE-KHAKI
14
13052
1
MAIN CIRCUIT BOARD FOR 28426
15
12772D
2
SIDE COVER FIXER
17
12771D
2
SIDE COVER BASE
20
12775W
1
DEFLATION OUTLET CAP
21
10064
1
SPA CONTROL PANEL FIXER-BROWN
22
12919
1
TRANSFORMER FOR SB-H20 BUBBLE SPA
23
12920
1
RECTIFIER BRIDGE FOR BUBBLE SPA（From 20201103 rectifier bridge built in main circuit board#13052）
From 20201103, Rectifier bridge built in Main circuit board#13052
From 20201103, Rectifier bridge built in Main circuit board#13052
From 20201103, Rectifier bridge built in Main circuit board#13052
）
27
11687
1
SPA CONTROL STATION AIR INLET O-RING
28
11746
1
AIR INLET CONNECTOR NUT FOR 28401/02/03/04
29
10836
1
RUBBER CAP FOR #03R/#638/#638R/638G/637R MOTOR
30
10840
1
RESISTANCE TO RUB WASHER FOR #03R/#638/#638R/638G/637R MOTOR
31
12077
1
CERAMIC BAR FOR 28401MW/28403/04/21/22/23/24/43/44/53/54 & 28402 MADE ON/AFTER 2013-12-10
32
12084
1
MAGNETIC ROTOR AND IMPELLER FOR 28404/28422/28444/28454 & 28402 MADE ON/AFTER 2013-12-10
33
12778
1
FILTER MOTOR FOR 28462
34
12580
1
20-40℃ TEMP. SENSOR FOR BUBBLE SPA MADE ON/AFTER OCT 1ST, 2016
35
12581
1
50℃ TEMP. SENSOR FOR BUBBLE SPA MADE ON/AFTER OCT 1ST, 2016
36
12029
1
84℃ TEMP. FUSE FOR 28402/28404 (14, 15 & 16 VERSION)
37
12310
1
OUTLET FLOW SENSOR FOR BUBBLE SPA (16 VERSION)
38
11745
1
WATER INLET/OUTLET CONNECTOR NUT FOR 28401/02/03/04 (KAKHI)
39
12918
1
WATER OUTLET TUBE FOR SPA-KHAKI
40
12006
1
SPA FILTER MOTOR CONNECTING TUBE
41
12751
2
FILTER MOTOR OUTLET O-RING FOR BUBBLE AND COMBO SPA
42
12601
1
BUBBLE SPA CONTROL BASE INLET HOSE W/ KAKHI NUT
