Intuitive DAVINCI XP - Camera Intraoperative Use; Camera Postoperative Instructions

da Vinci SP Instruments and Accessories
EndoWrist SP Camera
11
DRAFT/PRE-RELEASE/CONFIDENTIAL
12/5/19
Figure 2.7 Examples of incorrect installation (A and B) and correct installation (C)
2.3 Intraoperative Use
For information on intraoperative use (installation, insertion, and removal of the camera), refer
to the da Vinci SP System User Manual.
2.4 Postoperative Instructions
Camera Sheath Removal
CAUTION: Use caution when installing and removing the sheaths to avoid camera
shaft, elbow, or wrist damage. Use gloves with sufficient grip to aid with installation
and removal of the sheath.
Remove the sheath from the camera immediately after each procedure.
1. Press the clips on both sides of the sheath connector and pull up to disengage from the
flanges at the base of the shaft (
Figure 2.8).
Figure 2.8 Press the clips on the connector
A
B
C
Clips on
connector
AB
