Invacare 1900 - Raising;Lowering the Bath Lift; Using the Scale (Model 1900 S ONLY); Emergency Stop

SECTION 2—OPERATING THE BATH LIFT
Part No. 1148113 11 1900/1900S Bath Lift
15. Lockthetworearlockingcastersontheliftbypressingdownonthelockingpedal
withyourfoot.RefertoFIGURE 2.1.
16. Lockthebathingunitdoor.Refertothebathingunit’sowner’smanual.
Raising/Lowering the Bath Lift
NOTE:Forthisprocedure,referto
FIGURE 2.3.
Toraisethebathlift,presstheuparrow
buttononthehandpendant.
Tolowerthebathlift,pressthedown
arrowbuttononthehandpendant.
FIGURE 2.3 Raising/Lowering the Bath Lift
Using the Scale (Model 1900S ONLY)
NOTE:Forthisprocedure,refertoFIGURE 2.4.
1. Withtheseatemptyandarmslowered,turnonthescalebytouchingthe“on”button
onthefaceofthescale.
2. Pressthe“ZERO”buttononthefaceofthescale.
NOTE:Thedigitalreadoutshows0.0.
3. Usingthe“UNITS”button,selecteitherkilogramsorpounds.
4. Transfertheresidentontheseatoftheliftandlowerthearms.
5. Raisetheresident.
NOTE:Itisonlynecessarytoraisetheresident
untilhis/herfeetareoffthefloorandnot
touchingthelegsofthelift.
6. Pressthe“LOCK”key
7. Readandrecordtheweightofthe
resident
onthereadoutofthescale.
FIGURE 2.4 Using the Scale (Model 1900S
ONLY)
Emergency Stop
NOTE:Forthisprocedure,referto
FIGURE 2.5.
•PresstheREDemergencystopbutton
onthecontrolboxtostoptheliftseat
andresidentfromraisingorlowering.
•Todisengage,rotatetheRED
emergencystopbuttonCLOCKWISE
untilitpopsout.
FIGURE 2.5 Emergency Stop
RED Emergency Stop Button
Control Box
Press to Stop
Lift Seat
Rotate CLOCKWISE to
Disengage Emergency Stop
