6. Aftertenminutes,rinsetheseatsurface,safetystrap,shoulderstrap,armrests,and
anyothernon‐electronicsurfacewiththeshowerwandofthebath.Refertothe
individualbathingunit’sowner’smanualforusingtheshowerwand.
CAUTION
DO NOT spray the push handles, scale, or hand pendant with water. Sprayed water
may damage the electronic components of the lift.
7. Lightlywipethepushhandles,scale,andhandpendantwithadampcloth.
8. Dryallsurfaceswithacleantowel.
9. Removethebathliftfromthetub.ReverseSTEPS13to16inTransferringinto/outof
theBathingUnitonpage 9.
FIGURE 2.7 Disinfecting the Lift
Mounting the Battery Charger
NOTE:Forthisprocedure,refertoFIGURE 2.8.
NOTE:Refertoyourlocalregulationsconcerningpropermountingprocedures.
1. Placethebatterychargerwithmountingbracketonthewallatthedesiredposition.
2. Withapencil,markthemiddleholeposition.
3. Measuredown6½inchesfromthepencilmarkanddrillonemountinghole.
4. Installthebottommountingscrewuntilthereisanapproximate1/8‐inchgapbetween
thescrewheadandthewall.
5. Installthebatterychargerwithmountingbracketontothebottommountingscrew.
6. Drilltheremainingtwomountingholes.
7. Installthetworemainingmountingscrewsthroughthemountingbracketandintothe
wall.Tighten
securely.
8. Plugthebatterychargerintothewallelectricaloutlet.
NOTE:TheOnLEDshouldilluminate.
DETAIL “A” - NON ELECTRONIC SURFACES
Seat
Surface
Safety Strap
Arm Rests
Base
DETAIL “B” - ELECTRONIC SURFACES
Push
Handles
Hand
Pendant
NOTE:Shoulder
Strapnotshown.
Scale
