Removing/Installing the Safety Strap
 WARNING
DO NOT put the safety strap in the dryer. The high heat will melt the belt’s material.
NOTE:Forthisprocedure,refertoFIGURE 2.10.
NOTE:ThesafetystrapMUSTbewashedanddisinfectedaftereachuse.
1. Unbucklethesafetystrapbypullingupthehook‐and‐loopstriponthebuckle.
2. Pullthehook‐and‐loopstripthroughthebuckle(Detail“A”).
3. Removethesafetystrapfromthechair.
4. RepeatSTEPS1to3fortheotherside.
5. Wrapthenewsafetystraparoundtheliftframe.
6. Insertthehook‐and‐loopstripthroughthebuckleandsecureittothechairframe
(Detail“B”).
7. RepeatSTEPS5and6fortheotherside.
FIGURE 2.10 Removing/Installing the Safety Strap
Installing/Removing the
Shoulder Strap
NOTE:Forthisprocedure,referto
FIGURE 2.11.
NOTE:Toremovetheshoulderstrap,reverse
thisprocedure.
1. Insertthebeltthroughthebracketat
thetopofthechair.
2. Loopthehook‐and‐loopstripthrough
thebracketandsecurethestrap.
FIGURE 2.11 Installing/Removing the
Shoulder Strap
Buckle
Hook-and-Loop Strip
Chair Frame
Safety Strap
Buckle
Hook-and-Loop Strip
Chair Frame
Safety Strap
DETAIL “A”
DETAIL “B”
Shoulder
Strap
Chair
Hook-
and-Loop
Strip
