Part No. 1110545 25 A4™AND A4™TITANIUM
SECTION 4
FRAME
FRAME
75° BACK ANGLE TO SEAT RAIL
80° BACK ANGLE TO SEAT RAIL85° BACK ANGLE TO SEAT RAIL
95° BACK ANGLE TO SEAT RAIL 90° BACK ANGLE TO SEAT RAIL
Back Cane
Indexing
Notch
Cam
Back Angle
Bracket
Seat Rail
TOP Hex
Screw and
Locknut
Back
Cane
Indexing Notch
Cam
Back Angle Bracket
Seat Rail
TOP Hex
Screw and
Locknut
Back Cane
Indexing
Notch
Cam
Back Angle Bracket
Seat Rail
TOP Hex Screw
and Locknut
Back Cane
Indexing
Notch
Cam
Back Angle
Bracket
Seat Rail
TOP Hex
Screw and
Locknut
Back Cane
Indexing
Notch
Cam
Back Angle Bracket
Seat Rail
TOP Hex Screw
and Locknut
FIGURE 1 - BACK ANGLE ADJUSTMENT
