Part No. 1110545 63 A4™AND A4™TITANIUM
Section 8 - Arms includes the following:
Installing the T-Arm Sockets
Installing/Removing the T-Arms
Adjusting the T-Arms
Adjusting the T-Arm Transfer Assists and/or Side Guards
Replacing the T-Arm Locking Lever
Installing the Half Arm Socket
Adjusting Half Arm Height
WARNING
NEVER try to lift or tip the wheelchair by T- or half arms, serious injury
can occur.
After ANY adjustments, repair or service and BEFORE use, make sure all
attachment hardware is tightened securely - otherwise, injury or damage
may result.
INSTALLING THE T-ARM SOCKETS (FIGURE 1)
1. Remove the rear wheels from the wheelchair. Refer to REMOVING/INSTALLING
REAR WHEELS in SECTION 5 of this manual.
2. Position the inner T-arm bracket on the wheelchair frame as shown in FIGURE 1.
NOTE: The inner T-arm bracket must be positioned on the outside of the wheelchair frame.
3. Install the hex screws and washers through the inner T-arm bracket and loosely
tighten.
4. Tighten the hex screws and washers that secure the inner T-arm bracket to the
wheelchair frame.
5. Position T-arm bracket inserts between inner and outer T-arm brackets as shown in
FIGURE 1.
6. Secure the outer T-arm bracket to the inner T-arm bracket with the socket screws
and washers.
7. Repeat STEPS 2-6 for the opposite side of the wheelchair.
8. Install the T-arms into the T-arm sockets. Refer to INSTALLING/REMOVING THE
T-ARMS in this section of the manual.
ARMS SECTION 8
ARMS
