A4™AND A4™TITANIUM 40 Part No. 1110545
Wheelchair
Frame
FIGURE 10 - ADJUSTING WHEELBASE LENGTH
(ADJUSTING CENTER OF GRAVITY)
SHORTENING
Axle Tube
LENGTHENING
Top
Clamp
Socket Screw -
Loosen But Do Not
Remove
Back Post
Camber Clamp
DETAIL "A"
Measure this distance
Back Post
Top
Clamp
NON-SUSPENSION - TOP VIEW
SUSPENSION - SIDE VIEW
Top Clamp
Hex Screws
Wheelchair
Frame
Axle
Tube
FRAME
FRAME
SECTION 4
