Invacare Action 2 NG - Fastening the 3-Point Passenger Restraint System

Transport
1.Attachthesnaphookstotheorangeringsasshownin
thetwoguresabove(seelocationoftheattachment
labels).
2.Attachrearstrapstotherailsystemreferringtobest
practicerecommendedinstructionsfromthesafetybelt
manufacturer.
3.Tightenthestraps.
IMPORTANT!
–Makesurethatthesnaphooksarecovered
withslipresistantmaterialtoavoidlaterally
slippingontheaxle.
IMPORTANT!
–Checktheplungersarefullyengagedonboth
sidesandlocatedinthesamepositionofthe
cut-outsectionoftherail.
–Makesurethattheanglebetweentherailsand
thestrapsliesbetween40°and45°.
Fitposturebelt
WARNING!
Theposturebeltcanbeusedinadditiontobut
neverasasubstituteforanapprovedpassenger
restraintsystem(3-pointbelt).
1.Adjustposturebelttotthewheelchairoccupant,see
section4.2Posturebelt,page26.
Fasteningthe3-pointpassengerrestraintsystem
IMPORTANT!
Theillustrationabovemaydifferdependingon
therestraintsystemsupplier.
