Invacare®Action2NG
WARNING!
–Ensurethe3-pointpassengerrestraintsystem
tsastightlyacrosstheuser'sbodyaspossible
withoutdiscomfortandnopartistwisted.
–Ensurethe3-pointpassengerrestraintsystemis
notheldawayfromtheuser'sbodybypartsof
thewheelchairsuchasarmrestsorwheelsetc.
–Ensuretheuserrestrainthasaclearpath
fromtheusertotheanchorpointwithout
interferencebyanypartofthevehicle,
wheelchair,seatingoroption.
–Ensurethelapbelttssnuglyoverthe
occupant’spelvisandisnotallowedtorideup
intotheabdominalarea.
–Ensuretheuserisabletoreachtherelease
mechanismunaided.
1.Attachthe3-pointpassengerrestraintsystemreferring
totheusermanualsuppliedwithyour3-pointrestraint
system.
IMPORTANT!
–Applytheposturebeltofthe3-pointpassenger
restraintsystemlowacrossthepelvisso
thattheangleoftheposturebeltiswithin
thepreferredzone(A)of30°to75°tothe
horizontal.Asteeperangleispreferred,but
neverexceeding75°.
A
30°
75°
