3. Safety inspection and maintenance
3.1. Performance control
As the user, you will be the rst to notice any possible
operational defects with your wheelchair. The following table
indicates the easiest troubleshooting symptoms to identify
and the preliminary inspection that you can perform.
In the event that the symptoms persist after adjusting the
pressure in the tyres, please consult your retailer.
The inner tubes of the wheels are the only components that
you can repair yourself (see paragraph B-2.3).
If the screws and nuts are not tight enough or loose, the axle
fork angle is not perpendicular to the ground, please consult
your retailer to get a competent person to re-set them to
the correct position and tighten appropriately.
(Recommended torque minimum : M5 = 3-6 Nm;
M6 = 7-12 Nm & M8 = 10-20 Nm)
3.2. General inspection
Your distributor, who has the required technical expertise, is
responsible for any wheelchair repairs.
We recommend that you take the wheelchair to your
retailer at least once a year for a complete inspection.
Regular maintenance allows the identication and
replacement of defective and worn parts, which improves
the daily operation of your wheelchair.
Regular inspections to be performed by you or your
assistants :
a. General
Make sure that the wheelchair folds and unfolds easily.
Make sure that the wheelchair moves in a straight line. (no
resistance or deviation)
b. Manual brakes
Make sure that the manual brakes do not touch the moving
tyres.
Make sure that the manual brakes operate easily.
Make sure that the joints are not worn and do not have play.
c. Folding system
Check the folding system for worn or distorted parts.
d. Skirtguard/armrest upholstery
Make sure that all the ttings are properly tightened.
e. Armrests
Make sure that the armrests are rmly attached, but easy to
remove.
The
wheelchair
swerves
to the
right
The
wheelchair
swerves
to the left
The
wheelchair
turns or
moves
slowly
The
castors
lift
Creaking
and
clinking
Play in
the
wheelchair
Inspections
Make sure that
pressure in the
pneumatic tyre is
correct (cf. § B-2.3)
Make sure that the
bolts are tight
Check the adjustment
on the fork angle
Make sure that the
2 castors come in
contact with the
ground at the same
time

Invacare Action3 NG Specifications

General

Frame Material	Aluminum
Weight Capacity	125 kg
Foldable	Yes
Rear Wheel Size	24 inches
Footrests	Swing-away
Front Wheel Size	8 inches
Total Weight	14.5 kg
Armrests	removable
Seat Width	380 - 530 mm
Seat Height	38 - 51 cm
Overall Length	1060 mm (with legrests)
