The above indication is given to the user for
information only.
Any wheels position and/or angle fork adjustments to the
set up of your wheelchair should only be performed at
the direction of a competent person who has fully risk
assessed the implication of any changes to the wheelchair
conguration. Please consult your dealer.
Note : not available for Transit version.
2.2.3 Steering tubes
They provide seat dump (0°, 3° or 6°) based upon user’s
capacity, propulsion, desired oor-to-seat height and
selected front and rear wheels.
All these adjustments and changes of position must be
performed by a professional technician upon agreement by
your prescribing physician. Please consult with your dealer.
In "Active" position, the manual brake may unlock
after swinging the footrest support out.
In this particular case, we recommend to swing the footrest
support inside !
Active position is only compatible with 6'' front castors.
In "Active" position, it is necessary to use anti-tippers to
avoid any risk of tipping backwards when you drive on a
slope !
(See paragraph 2.6.3)
2.3. Rear wheels
2.3.1 24" & 22" wheels
The 24" (610 mm) rear wheels are spoked or composite
wheels; the 22" (550 mm) wheels are only spoked wheels.
They can be delivered with pneumatic or solid tyre.
The 24" spoked wheels can optionally accommodate spoke
guards to prevent injuring the ngers during propulsion.
A at tyre (photo 21) must be removed in order to be
repaired. Remove the rim assembly (tyre and inner tube),
repair or replace the inner tube, reinsert in the tyre and
reposition the assembly on the rim.
Comply with the ination pressure specied on the sidewall
of the tyre.
Note :
remember that in order to maintain the
interchangeability of the chair wheels equipped with quick-
release axles, the pressure in the two tyres should be the
same.
21
